Cedar Mountain Formation

File:Placeholder

The Cedar Mountain Formation is the name given to distinctive sedimentary rocks in eastern Utah that occur between the underlying Morrison Formation and overlying Naturita Formation (sometimes incorrectly called the Dakota Formation). It is composed of non-marine sediments, that is, sediments deposited in rivers, lakes and on flood plains. Based on various fossils and radiometric dates, the Cedar Mountain Formation was deposited during the last half of the Early Cretaceous, about 127 - 98 million years ago (mya).

Dinosaurs occur throughout the formation, but their study has only occurred since the early 1990s. The dinosaurs in the lower part of the formation differ from those in the upper part. These two dinosaur assemblages, characterized by distinct dinosaurs, show the replacement of older, European-like dinosaurs with younger, Asian-like dinosaurs as the North American Continental Plate drifted westward. A middle dinosaur assemblage may be present, but the fossil record is not clear.

The formation was named for Cedar Mountain in northern Emery County, Utah, where William Lee Stokes first studied the exposures in 1944.[1] Only recently did the 125 m (410 ft) thick formation get subdivided into smaller, distinctive beds called members. There is a debate as to whether there are five members[2] or four[3] depending whether the Buckhorn Conglomerate is considered to be at the top of the Morrison Formation or at the base of the Cedar Mountain Formation; most geologists and paleontologists consider it part of the Cedar Mountain Formation. In ascending order the remaining members are the Yellow Cat Member, Poison Strip Sandstone, Ruby Ranch Member, and the Mussentuchit Member. Each of these members are named after a geographic area where they were first studied.

Stratigraphy

The Cedar Mountain Formation is sandwiched between the Morrison Formation below and the Naturita Formation and Mancos Shale above. The youngest date for Morrison just below the Cedar Mountain Formation is 148.1 ± 0.5 Ma .[4] or lower Tithonian. Typically, the Jurassic-Cretaceous boundary in western North America is marked by an unconformity of variable length, and typically signifies 10-49 million years of missing geologic time.[4] This boundary between the Morrison and Cedar Mountain is commonly marked by a horizon of carbonate nodules[5][6] or by highly polished pebbles that are allegedly gastroliths.

• The Buckhorn Conglomerate is considered the lowermost member of the Cedar Mountain Formation in the region of the San Raphael Swell by Stokes.[5] It is named for exposures near Buckhorn Reservoir near Cedar Mountain. Its position immediately below the Ruby Ranch Member suggests that it may be equivalent to the channel sandstones in the Yellow Cat Member and the Poison Strip Sandstone farther to the east. This idea is strengthened by the similar composition of the gravels in these members, but a direct correlation has not yet been established.
• The Yellow Cat Member is named for exposures near the Yellow Cat mining area north of Arches National Park. It is limited to the eastern portions of the formation and is thickest near Arches National Monument. The member is composed of drab greyish mudstones and some lenses of sandstone. The mudstones were deposited on flood plains, and show evidence of ancient soil development called paleosols. The mudstones originated as flood deposits from river channels that are marked by the sandstone lenses. A recent radiometric date of 126 ± 2.5 Ma places Yellow Cat Member in the Barremian,
• The Poison Strip Sandstone was named for prominent, cliff-forming sandstones in the Poison Strip uranium district north of Arches National Monument. It is actually a series of sandstones that were deposited in river channels, and lesser amounts of mudstones and limestones that were deposited on the flood plain and small ponds. The Poison Strip Sandstone may represent a meandering river complex.[8] Based on the position of the Poison Strip between the Yellow Cat and Ruby Ranch members, it probably was latest Barremian to earliest Aptian.
• Volunteers from the Denver Museum of Natural History discovered Tony's Bone Bed in 1998 in the Poison Strip Member.[9] Prior to that, Poison Strip dinosaurs were only known from possible Sauropelta and isolated theropod and sauropod bones.[10] Tony's bone bed is 3.75 m below the top of the poison strip.[8] Quality of the bones are "highly variable."[11] Ends of bones may have been damaged by scavenging.[11] Some of the bones may have been trampled.[11] Some of the vertebrae preserve "delicate lamina".[11] None of the bones were articulated so they were probably not buried quickly after death.[11] Tony's Bonebed probably accumulated over time when the water in the river channel was low during the dry season.[11] Carbonate growths appear on bones in the quarry from which Venenosaurus was extracted.
• The Ruby Ranch Member is the most widespread and distinctive member of the Cedar Mountain. It was named for exposures on the Ruby Ranch located southeast of Green River, Utah. The member is composed of maroon mudstones with irregular spheres of carbonate nodules. The nodules formed in ancient soils that developed in the mud deposited on the flood plain in a strongly seasonal, semiarid climate. Evaporation of groundwater during the dry season concentrated calcium carbonate and other minerals in the upper parts of the soil horizon. Radiometric dates place the upper portions of the Ruby Ranch in the late Aptian. Exhumed river channels in the Ruby Ranch indicate that stream flow during the Aptian was towards the northeast, the direction of the encrouching Western Interior Seaway.
• The Mussentuchit Member is the uppermost member of the Cedar Mountain Formation. It was named for exposures along Mussentuchit Wash southwest of the San Rafael Swell. It is predominantly composed of grey mudstones high in organic carbon from fossil plant material, as well as volcanic ash. The mudstones were originally deposited on a broad coastal plain with a high water table or with abundant rainfall. Thus, carbonate nodules are rare. A radiometric date of 98.37 ± 0.07 Ma places the upper part of the member in the Lower Cenomanian, while lower portions of the member have been dated to 104.46 ± 0.95 Ma, in the Albian stage.
• Although not part of the Cedar Mountain Formation, the Naturita Formation immediately overlies the Cedar Mountain and marks the encroaching Western Interior Seaway. The Naturita is not uniformly distributed and was eroded away in places by the advancing Seaway so that the marine shales of the Mancos Formation lay directly on the Mussentuchit or its equivalent. The name Dakota Formation has been improperly used for these strata.

Dinosaurs

The Cedar Mountain Formation is one of the last major dinosaur-bearing formations to be studied in the United States. Although sporadic bone fragments were known prior to 1990, serious research did not begin until that year. Since then, several organizations have conducted field work collecting dinosaurs, chiefly the Oklahoma Museum of Natural History, the Denver Museum of Nature & Science, the College of Eastern Utah, the Utah Geological Survey, Brigham Young University, and Dinosaur National Monument staff. This research indicates that at least two, possibly three dinosaur assemblages are contained within the formation.

The oldest of these assemblages is from the Yellow Cat, Poison Strip and basal Ruby Ranch members. The small, Ornitholestes-like theropod Nedcolbertia and the brachiosaurid sauropod Cedarosaurus may be considered as relics, with their closest relatives in the Morrison Formation. In contrast, the polacanthid ankylosaur Gastonia and a yet unnamed iguanodontid are similar to related forms from the Lower Cretaceous of southern England. These dinosaurs show that the connection between North America and Europe still existed during the Barremian. All of this changes, however, with the upper dinosaur assemblage from the top of the Ruby Ranch and Mussentuchit members. This upper assemblage shows greater similarities with Asian dinosaur assemblages from the same time. For example, the primitive ankylosaurid Cedarpelta is related to Gobisaurus and Shamosaurus from Mongolia, but is more primitive than either because it has teeth in the premaxilla. The upper assemblage also has a tyrannosaurid, a ceratopsian, and a pachycephalosaur. Although not a dinosaur, the primitive mammal Gobiconodon is known from both Mongolia and the Mussentuchit Member. Evidence for a middle dinosaur assemblage between the older and younger ones is controversial because the evidence mostly depends on a single specimen of the ornithopod Tenontosaurus from high in the Ruby Ranch Member and the sauropod Astrodon from low in the Ruby Ranch. Regardless, the upper and lower dinosaur assemblages in the Cedar Mountain Formation document the separation of North America and Europe, the westward drift of North America, and its connection with Asia 10 to 15 million years later.[14]

Data from Carpenter (2006),[14] Cifelli et al. (1999),[15] Kirkland and Madsen (2007), and The Paleobiology Database.

Ankylosaurs

Ankylosaurs reported from the Cedar Mountain Formation
Genus	Species	Location	Member	Material	Notes	Images
Animantarx	Animantarx ramaljonesi		* Mussentuchit Member.	"Partial skull [and] skeleton."		File:Animantarx 04829.JPG Animantarx
Cedarpelta	Cedarpelta bilbeyhallorum		* Mussentuchit Member	"Skull [and] postcranium."	Cedarpelta bilbeyhallorum was not from the Ruby Ranch Member as initially described.
Gastonia	Gastonia burgei		* Yellow Cat Member	"[Two] skulls, [two] partial skulls, [and four] or [five] partial skeletons."
	Unnamed		* Ruby Ranch Member.
Peloroplites	Peloroplites cedrimontanus		* Mussentuchit Member.
Sauropelta	Unnamed			"Skull and partial skeleton, isolated sacrum."		Sauropelta

Marginocephalians

Indeterminate neoceratopsian present in the Mussentuchit Member. Indeterminate pachycephalosaurid present in the Mussentuchit Member.

Ornithopods

New genus and species of iguanodont present in the Ruby Ranch and Yellow Cat members.

Ornithopods reported from the Cedar Mountain Formation
Genus	Species	Location	Member	Material	Notes	Images
Cedrorestes	Cedrorestes crichtoni		Yellow Cat Member.			File:Eolambia.png Eolambia Tenontosaurus
Eolambia	Eolambia caroljonesa		Mussentuchit Member.
Hippodraco	Hippodraco scutodens		Yellow Cat Member.
Iguanocolossus	Iguanacolossus fortis		Yellow Cat Member.
Iguanodon	I. ottingeri			"Teeth."	Dubious.
Planicoxa	Planicoxa venenica		Poison Strip Member.	"Associated postcranium."
Tenontosaurus	Tenontosaurus sp.		Mussentuchit Member Ruby Ranch Member
Zephyrosaurus	cf. Zephyrosaurus sp.		Mussentuchit Member.

Sauropods

New titanosaurid genus and species present in the Yellow Cat Member. Indeterminate brachiosaurid remains present in the Mussentuchit Member.

Sauropods reported from the Cedar Mountain Formation
Genus	Species	Location	Member	Material	Notes	Images
Abydosaurus			Mussentuchit Member			File:Astrodon1DB.jpg Astrodon File:Brontomerus utahraptor2.jpeg Brontomerus
cf. Astrodon	Indeterminate		Ruby Ranch Member.
Cedarosaurus	Cedarosaurus weiskopfae		Yellow Cat Member.	"Postcranial skeleton."
Venenosaurus	Venenosaurus dicrocei		Poison Strip Member.	"Partial postcranial skeleton."
Brontomerus	Brontomerus mcintoshi		Ruby Ranch Member.

Theropods

Indeterminate dromaeosaurine present in the Mussentuchit Member. Indeterminate velociraptorine remains present in the Mussentuchit Member. Possible indeterminate tyrannosaurid remains present in the Mussentuchit Member. Indeterminate troodontid remains present in the Mussentuchit Member. Indeterminate therizinosaurid remains present in the Mussentuchit Member. Indeterminate dromaeosaurine remains present in the Mussentuchit Member. Possible new allosaurid species present in the Ruby Ranch Member. Possible indeterminate hesperornithiformes present in the Mussentuchit Member.

Theropods reported from the Cedar Mountain Formation
Genus	Species	Location	Member	Material	Notes	Images
cf. Acrocanthosaurus	Indeterminate		Ruby Ranch Member.			Acrocanthosaurus File:Falcarius utahensis DWER 500.JPG Falcarius Utahraptor ostrommaysorum
Deinonychus	Indeterminate		Mussentuchit Member.
Falcarius	Falcarius utahensis		Yellow Cat Member.
Geminiraptor	Geminiraptor suarezarum		Yellow Cat Member.
Martharaptor	Martharaptor greenriverensis		Yellow Cat Member.
Nedcolbertia	Nedcolbertia justinhofmanni		Yellow Cat Member.	"Partial skeletons of [three] individuals."
cf. Richardoestesia	Indeterminate		Mussentuchit Member.
Siats	Siats meekerorum		Mussentuchit Member.	"Partial postcranial skeleton of immature individual."
Utahraptor	Utahraptor ostrommaysorum		Yellow Cat Member.	"Skull and postcranial fragments."
	Indeterminate		Poison Strip Member.
Yurgovuchia	Yurgovuchia doellingi		Yellow Cat Member.
